Pharmaceutical Machinery

Ointment
Semi-Automatic Tube Filling and Sealing Machine

NF-30

Semi-Automatic Tube Filling and Sealing Machine

Tube filler & sealer for automated filling and closing of plastic and aluminum tubes
  • 10 to 30 Tubes Per Minute
  • 5 to 250ml Filling Range
Request a Quote
Semi-Automatic Tube Filling and Sealing Machine Semi-Automatic Tube Filling and Sealing Machine Semi-Automatic Tube Filling and Sealing Machine Semi-Automatic Tube Filling and Sealing Machine Semi-Automatic Tube Filling and Sealing Machine Semi-Automatic Tube Filling and Sealing Machine

The semi-automatic tube filling and sealing machine ensures precise filling and stable sealing. Designed with 8 working stations, the tube filler automates all processes except manual tube feeding. The shape and size of the seals can be easily adjusted to meet user-specific requirements, making it a versatile choice for various industries.

Applications

This semi-automatic tube filling equipment is ideal for use in the cosmetics, pharmaceutical, adhesive, and shoe polish industries, as well as other related sectors.

Semi-Automatic Tube Filling and Sealing Machine
Key features
  • All components feature quick-release connections, enabling easy disassembly and cleaning.
  • Equipped with a hot air sealer for cutting off the end of the tube to prevent the accumulation of cut-off material from the tube ending on the worktable (specific to plastic tubes).
  • Includes a no-tube-no-filling function to prevent material wastage and pneumatic components that stop operation when necessary.
  • All parts in contact with product are made of high-quality stainless steel, with easy-to-clean quick-change components for convenience.
  • For materials requiring temperature control, the tube filling machine can be equipped with a heated and temperature-controlled barrel.
Specifications
Model NF-30
Production Capacity 10-30 tubes/min
Filling Range 5-250ml (aluminum tube) Additional charge will be made for 200-250ml tube
Filling Accuracy ±1%
Working Pressure ＞0.4MPa
Power Supply 220V±10%
Power 750W
Machine Dimensions (L×W×H) 1200×820×1650mm
Machine Weight 350kg
