High Speed Tablet Press

GZPK Series

High Speed Tablet Press

Tablet press machine combining high automation and precision in tablet production
  • 65,000 to 95,000 Tablets Per Hour
  • Up to 20 mm Tablet Diameter
  • Up to 20 mm Length of Irregular Tablet
Request a Quote
High Speed Tablet Press High Speed Tablet Press High Speed Tablet Press High Speed Tablet Press High Speed Tablet Press High Speed Tablet Press

The high speed tablet press is a highly advanced machine designed for the pharmaceutical industry. It combines automation technology with high-precision control to ensure efficient and accurate tablet production. Equipped with a Siemens PLC system and a touchscreen interface, it offers intuitive operation and significantly enhances production efficiency.

With its intelligent automated control features, the high speed tablet pressing machine includes automatic tablet weight adjustment, hydraulic system stabilization, and fault alarm protection. These functions reduce labor costs, improve product quality, and ensure high compliance rates. The reject system for non-conforming tablets ensures that every tablet produced meets the required standards, delivering a reliable solution for high-quality pharmaceutical manufacturing.

Applications

The high speed tablet press is designed to produce a wide range of conventional tablets, such as vitamin tablets, anti-allergy tablets, and digestive tablets.

Key Features
  • Equipped with high-precision TEDEA-HUNTLEIGH sensors to monitor pressure in real time and automatically adjust powder filling depth.
  • Adjusts tablet weight and reduces material variance automatically to ensure uniformity.
  • Users can set upper and lower limits for hydraulic pressure, ensuring stable and reliable operation.
  • Includes multiple alarm and fault protection features, such as door/window safety, low lubrication, and overload alarms.
  • Flexible reject system automatically identifies and removes non-conforming and defective tablets, either individually or in batches, ensuring quality control.
Specifications
Model GZPK-15 GZPK-17 GZPK-20
Production Capacity 65,000pc/h 75,000pc/h 95,000pc/h
Number of Stations 15 17 20
Max. Tablet Diameter 25mm 16mm 13mm
Max. Length of Irregular Tablet 25mm 18mm 16mm
Max. Main Pressure 100kN 80kN 80kN
Max. Pre-pressure 12kN 12kN 12kN
Max. Filling Depth 20mm 16mm 16mm
Die Diameter 38.1mm 30.16mm 24.01mm
Punch Length 133.5mm 133.5mm 133.5mm
Tablet Thickness Range 0.5-10mm 0.5-8mm 0.5-8mm
Total Power 5.5kW
Machine Weight 675kg
Machine Dimensions 680×650×1690mm
